#EpochDB — Agentic Memory Engine

EpochDB is a high-performance, state-aware memory engine designed for lossless, tiered storage, atomic state management, and multi-hop relational reasoning. It is built specifically for AI agents that require perfect historical recall, long-term state persistence, and deterministic fact corrections.

[!NOTE] Looking for a distributed, sharded deployment? Check out the EpochDB Distributed Server repository for multi-node clustering, consistent-hashing-based horizontal sharding, and high-concurrency coordinator routing.

---

#Why EpochDB?

Flat vector databases retrieve text based on semantic similarity but struggle to resolve conflicting facts (e.g. "where does the user work now?" vs "where did they work last year?"). EpochDB solves this through Atomic State Management:

• Topic Lock & Entity Seeding: Ensures retrieval stays within the target topic by seeding candidates directly from the Knowledge Graph.
• State-Aware Supersession: Automatically identifies and filters out stale facts when they are updated.
• Adaptive Query Routing & Decomposition: Dynamically routes incoming queries to optimal search engines (semantic, relational, temporal, or quantitative) or splits composite queries using LLMs (Gemini, OpenAI, Anthropic) or local offline rules.
• Contextualized Retrieval (Temporal neighbor expansion): Retrieves chronological context turns immediately surrounding matched memories.
• Tiered HNSW Hierarchy: Sub-millisecond recall across working memory (L1 RAM) and a probed subset of historical archives (L2 Disk) — recency, entity routing, and epoch centroids, with an exhaustive fallback.
• Memory Forking & Lineage: Supports logical branches (db.fork) for multi-agent collaboration and hypothetical reasoning without copying data.
• Pairwise Entity Graph Extraction: Automatically generates co-occurrence relationship triples between extracted entities for connected graph visualizations.
• Rich Domain Objects: Returns structured Memory, Entity, and Graph abstractions rather than raw database tuples.
• Neuro-Symbolic State Verification (LCAG): Opt-in two-phase propose() commits — stage → symbolic validate → atomic WAL/HNSW/KG write — so agents cannot mutate durable state without deterministic rule approval.

---

#Architecture

EpochDB uses a tiered hierarchy modeled after CPU caches to balance low latency and massive scale:

graph TD
    Agent([Agent / Application]) -->|remember / add_memory| Engine[EpochDB Engine]
    Agent -->|propose intent| Stage[Staging Area PENDING]

    Stage --> Val[Symbolic Validators]
    Val -->|APPROVED| Engine
    Val -->|REJECTED| Reject([Return error / discard])

    subgraph "Working Memory — RAM (Hot Tier)"
        Engine --> HNSW_H[HNSW Vector Index]
        Engine --> WAL[WAL: ACID Write-Ahead Log]
        Engine --> KG[Active Knowledge Graph]
    end

    subgraph "Historical Archive — Disk (Cold Tier)"
        HNSW_H -->|Async Flush| Parquet[(Parquet + F32 + Zstd)]
        Parquet --- HNSW_C[HNSW Index per Epoch]
        HNSW_C --- GEI[Global Entity Index]
        HNSW_C --- Centroids[Epoch Centroids]
    end

    subgraph "Retrieval Pipeline"
        HNSW_H --> Pool[Candidate Pool]
        HNSW_C --> Probe[Epoch Probe: recency + GEI + centroids]
        Probe --> Pool
        Pool --> KG_Exp[KG Expansion & Topic Lock]
        KG_Exp --> RRF[4-Way RRF Fusion + Supersession]
        RRF --> Context[Agentic Context]
    end

Opt-in write path: db.remember() remains the zero-overhead default. Pass validators=[...] and use db.propose() only when you need Logical Constraint-Augmented Generation (LCAG) before durable commit.

---

#Performance, Latency & Token Efficiency

#1. The 1.000 Sweep Benchmark

EpochDB achieves a perfect 1.000 score across named benchmark suites designed to validate engine logic:

Run the benchmark suite locally:

venv/bin/python -m benchmarks.run_all

#2. Operational Latency

Precision metrics across Hot and Cold tiers:

• Direct/Multi-Hop Relational Retrieval (Hot Tier): 0.2 ms – 0.4 ms
• Historical HNSW Retrieval (Cold Tier): ~4.0 ms (30x speedup from ~125 ms via persistent indexing)
• Cold Tier Full Scan (pyarrow.dataset): 45.0 ms (for cross-epoch scalar aggregations)
• Scalar Range Query (B-tree): 0.8 ms
• Series Interpolation (IntervalTree): 1.2 ms
• Constraint Satisfaction (Z3 SAT Solver): 2.5 ms
• WAL Crash Recovery Replay: 9.1 ms

#3. LangGraph Token Savings

When used as a checkpointer, EpochDB keeps LangGraph states "thin" by storing historical turns as Unified Memory Atoms and querying them selectively. This achieves linear $O(N)$ token scaling (saving 55% to 79% of input tokens compared to standard checkpointers' quadratic $O(N^2)$ accumulation).

#4. Sync vs. Async Concurrency Benchmark

This benchmark evaluates E2E latency and input token consumption under concurrent multi-user load, comparing three execution configurations:

1. Sync LangGraph + Sync EpochDB: Sequential graph invocation with blocking I/O.
2. Async LangGraph + Async EpochDB: Concurrent graph execution (ainvoke) using async checkpointers and DB facades.
3. Async Aster + EpochBlackboard: Decoupled event-driven reactive coordination running in parallel.

The scenario simulates 3 concurrent users executing 10 conversation turns each (30 turns total) over the live Gemini API:

#Configuration A: Cloud API Embeddings (gemini-embedding-2 3072D)

Under this configuration, all text embedding vectors are generated remotely via the Gemini API, requiring sequential HTTP latency for embedding calls.

Key Insight: Remote embedding requests introduce sequential round-trip latency. In the sync baseline and standard async, these network calls pile up. Aster runs a decoupled event pool which hides network round-trip overhead through maximum event-driven parallelism (yielding 8.83x speedup).

#Configuration B: Local Embeddings (barisaydin/gte-base 768D)

Under this configuration, all text embedding vectors are generated locally using the SentenceTransformer model loaded in RAM, removing all network latency for embedding calls.

Key Insight: Eliminating remote embedding API calls slashes E2E latency across all configurations. The async pipeline collapses the blocking network time of LLM text generation down to a single user's duration (~60s), showing a clean 3.08x speedup.

Run the benchmark suite locally:

.venv/bin/python examples/sync_async_benchmark.py

---

#Installation

pip install epochdb

---

#Quickstart

#1. Synchronous API Facade

from epochdb import EpochDB

# Initialize with auto-embedding
with EpochDB(storage_dir="./memory", embedding_model="all-MiniLM-L6-v2") as db:
    # Store a memory with KG triples
    db.remember("User works at DataFlow.", metadata={"triples": [("user", "works_at", "DataFlow")]})

    # Update facts (supersession resolves conflicts)
    db.remember("Actually, user now works at VectorAI.", metadata={"triples": [("user", "works_at", "VectorAI")]})

    # Query returns rich Memory objects
    results = db.query("Where does the user work?", k=1)
    print(results[0].text)  # "Actually, user now works at VectorAI."

#2. Asynchronous API Facade

import asyncio
from epochdb import AsyncEpochDB

async def main():
    # Async context manager for non-blocking I/O in agent loops
    async with AsyncEpochDB(storage_dir="./memory", embedding_model="all-MiniLM-L6-v2") as db:
        await db.remember("VectorAI develops CRISPR-X platform.", metadata={"triples": [("VectorAI", "develops", "CRISPR-X")]})

        results = await db.query("What does VectorAI build?", k=1)
        print(results[0].text)

asyncio.run(main())

#3. MongoDB-Style Metadata Filtering

# Filter retrieval using operators like $eq, $ne, $in, $nin, $gt, $gte, $lt, $lte
results = db.query(
    "Query text",
    k=5,
    filters={
        "author": "Jeff",
        "importance": {"$gt": 3},
        "category": {"$in": ["development", "production"]}
    }
)

#4. Soft-Delete & Compaction

# Mark memory as deleted (filtered out from queries by default)
db.delete(memory_id, hard=False)

# Reclaim space and deduplicate historical Parquet archives in the Cold Tier
db.compact()

#5. Entity & Graph Traversal

# Retrieve entity object
vector_ai = db.get_entity("VectorAI")

# Traverse relations in Global Entity Index
related = vector_ai.related()  # [Entity("user"), Entity("CRISPR-X")]

# Chronological timeline of the entity
timeline = vector_ai.timeline()

# Generate local graph segment
graph = db.entity_graph("VectorAI", depth=2)
print(graph.nodes)  # ['VectorAI', 'user', 'CRISPR-X']
print(graph.edges)  # List of edge dictionaries mapping sources and targets

#6. Configurable / async triple extraction

from epochdb import EpochDB

db = EpochDB(
    storage_dir="./memory",
    embedding_model="all-MiniLM-L6-v2",
    auto_extract=True,                 # enrich KG on write
    extraction_model="hf:small",       # or "hf", "google:gemini-2.5-flash", "openai:gpt-4o-mini", "local"
    async_extract=True,                # non-blocking (default)
)

# remember() returns immediately; model extraction merges triples in the background
mid = db.remember("Alice joined VectorAI as a research engineer.")

# Optional: wait until background jobs finish
db.wait_for_extractions()
print(db.get(mid).triples)

# Switch backends at runtime (same prefix style as embedding models)
db.set_extraction_model("google:gemini-2.5-flash")
db.set_extraction_model("hf:Babelscape/rebel-large")
db.set_extraction_model("local")

Install local HF extraction with: pip install epochdb[extraction]

#7. Neuro-Symbolic State Verification (propose)

Prevent probabilistic agent writes from mutating durable state until deterministic rules approve. Validation is strictly opt-in — omit validators and both remember() and propose() skip the verification loop.

from epochdb import (
    EpochDB,
    SymbolicValidator,
    ValidationResult,
    ValidationStatus,
)

class RequireAdminRole(SymbolicValidator):
    def verify(self, text, metadata, kg_snapshot):
        if (metadata or {}).get("role") != "admin":
            return ValidationResult(
                ValidationStatus.REJECTED,
                reason="role must be admin",
            )
        # kg_snapshot: entities, predicates, epoch_id, hot_atom_ids, pending_ids
        return ValidationResult(ValidationStatus.APPROVED)

with EpochDB(
    storage_dir="./memory",
    embedding_model=None,
    validators=[RequireAdminRole()],
) as db:
    # Stage → validate → atomic WAL + HNSW + KG commit
    ok = db.propose("Rotate production credentials", metadata={"role": "admin"})
    # {"status": "APPROVED", "memory_id": "..."}

    bad = db.propose("Rotate production credentials", metadata={"role": "guest"})
    # {"status": "REJECTED", "error": "role must be admin"}

    # Unchanged zero-overhead path (bypasses validators)
    db.remember("Informational note that does not need LCAG")

Subclass SymbolicValidator for Python rules today; the same interface is intended for future Rust/Z3 SMT bridges.

---

#Client-Server Architecture

EpochDB supports remote deployments via a client-server architecture, allowing multiple agents or server processes to share a single, central database over HTTP.

[!TIP] While the built-in server is ideal for single-node deployments, you can use the EpochDB Distributed Server for production environments that require horizontal sharding, multi-node clustering, gateway caching, and consistent hashing.

#1. Starting the Server (ThreadingEpochDBServer)

Start the multi-threaded HTTP server on the host machine to serve an EpochDB instance:

from epochdb import EpochDB
from epochdb.api.server import start_server

db = EpochDB(storage_dir="./shared_memory", embedding_model="all-MiniLM-L6-v2")
server = start_server(db, host="0.0.0.0", port=8080)

try:
    server.serve_forever()
finally:
    db.close()

#2. Communicating via the Client (RemoteEpochDB)

Use the remote client to execute queries, store memories, and retrieve timelines over HTTP REST (optionally specifying consistency levels like "one", "quorum", or "all" for sharded/replicated environments):

from epochdb import RemoteEpochDB

# Initialize the client
client = RemoteEpochDB(host="127.0.0.1", port=8080)

# Store a memory with explicit quorum consistency
client.remember("Pollyanna is married to Jefferson.", consistency="quorum")

# Query the remote database
results = client.query("Who is Pollyanna married to?", k=1)
print(results[0].text)  # "Pollyanna is married to Jefferson."

# Access database stats remotely
stats = client.stats()
print(stats)

---

#Multi-Tenant Partitioning & WAL Optimizations

#1. Multi-Tenant Isolation

For multi-tenant SaaS platforms or isolated agent sessions, EpochDB can physically partition database files on disk using the tenant parameter:

# Database files are physically isolated under the "tenants/tenant_alpha" subdirectory
db = EpochDB(storage_dir="./app_data", tenant="tenant_alpha")

#2. Configurable WAL Sync Interval

By default, the Write-Ahead Log (WAL) synchronously forces an fsync call to disk on every transaction append, ensuring zero data loss but limiting write throughput. You can speed up writes dramatically by configuring asynchronous background syncing:

# Sync the WAL file to disk asynchronously every 0.1 seconds in a background thread
db = EpochDB(storage_dir="./memory", wal_sync_interval=0.1)

#3. Parquet Compression Configuration

When serializing working memory from the Hot Tier (RAM) to the Cold Tier (disk Parquet files), you can define the compression algorithm and level:

# Configure Zstandard compression (level 3) for disk archives
db = EpochDB(storage_dir="./memory", parquet_compression="zstd", parquet_compression_level=3)

Supported methods include "zstd", "snappy", "lz4", "gzip", "brotli", and "none" (defaulting to "zstd" with level 3).

#4. High-Performance io_uring WAL

On Linux hosts, EpochDB automatically compiles and loads a C shared library to write WAL appends through io_uring and Direct I/O (O_DIRECT), bypassing the kernel page cache and system call scheduling overhead to deliver up to 5x speedups on synchronous operations with natural queue backpressure safety.

#5. DuckDB SQL Analytics over Cold Tier Archives

EpochDB integrates with DuckDB to allow executing high-performance vectorized SQL queries over historical memory archives (*.parquet). The cold_tier view is registered automatically:

# Execute vectorized SQL aggregations over all historical Parquet archives
results = db.query_sql("""
    SELECT
        COUNT(*) as total_memories,
        AVG(scalar_value) as avg_value
    FROM cold_tier
    WHERE scalar_unit = 'degC'
""")

---

#LangGraph Integration

EpochDB provides native checkpointer support for both synchronous and asynchronous workflows:

from epochdb.checkpointer import EpochDBCheckpointer
from epochdb import EpochDB

# Synchronous compile
with EpochDB(storage_dir="./agent_state") as db:
    checkpointer = EpochDBCheckpointer(db)
    app = workflow.compile(checkpointer=checkpointer)

For async runtimes:

from epochdb import AsyncEpochDB
from epochdb.checkpointer import EpochDBCheckpointer

async def run_agent():
    async with AsyncEpochDB(storage_dir="./agent_state") as db:
        checkpointer = EpochDBCheckpointer(db)
        app = workflow.compile(checkpointer=checkpointer)
        # Uses aput, aget_tuple, and alist internally under the hood

---

#Configuring Embedding Providers

EpochDB supports multiple local and cloud embedding providers:

1. Local Offline Models (Default): Pass any SentenceTransformer model name (e.g. "all-MiniLM-L6-v2").

   db = EpochDB(storage_dir="./memory", model="all-MiniLM-L6-v2")


2. OpenAI & Compatible APIs: Use the openai: prefix.
   • Requires OPENAI_API_KEY set in your environment.
   • You can optionally set OPENAI_BASE_URL to route requests to local proxies (e.g., vLLM, LM Studio, Ollama) or compatible cloud endpoints (e.g. Voyage AI, Cohere).
   • Ensure the dim parameter matches your target dimensions (e.g., 1536 for text-embedding-3-small or any custom dimension supported by the model).

   db = EpochDB(storage_dir="./memory", model="openai:text-embedding-3-small", dim=1536)


3. Google / Gemini API: Use the google: prefix.
   • Requires GEMINI_API_KEY set in your environment.

   db = EpochDB(storage_dir="./memory", model="google:text-embedding-004", dim=768)


4. Ollama Local Service: Use the ollama: prefix.
   • Requires a running local Ollama service.

   db = EpochDB(storage_dir="./memory", model="ollama:all-minilm", dim=384)


#Repository Structure

The codebase is modularized to isolate engine subsystems:

• core/: Core transactions, checkpointers, and base units.
• storage/: Hot Tier (RAM HNSW + staging area) and Cold Tier (Parquet storage).
• entities/: Global KG manager, cascade updates, and reflection rules.
• validation/: Symbolic validators and LCAG two-phase commit interfaces (propose).
• retrieval/: Multi-stage retrieval managers, quantitative indexes, and RRF fusion.
• api/: Public facade APIs (EpochDB and AsyncEpochDB) and domain objects (Memory, Entity, Graph).

---

#Technical Specifications & Constants

• +20.0 Topic Lock Boost: Set mathematically larger than the maximum possible Reciprocal Rank Fusion (RRF) score sum (which caps at $\approx 0.05$ across semantic and recency ranks, using $K=60$). This acts as a "hard lock," ensuring query-intent-matched facts always outrank adjacent semantic noise.
• 0.0001x Supersession Penalty: Multiplicatively demotes stale facts (e.g. older conflicting values for the same subject-predicate pair) to the bottom of the retrieval pool, resolving contradictions deterministically while preserving database history.
• 1e-7 Signal-to-Noise Demotion: Once a Topic-Locked fact is identified, all non-locked background noise is demoted by $10^{-7}$ to keep the LLM's context window clean and free from distractors.
• Quantitative logic & Triggers: Native support for Scalars, Time-Series, and Constraints. IntervalTree enables precise $O(\log n + k)$ range queries with base-unit normalization via persistent schema_registry.json.
• Reactive Cascade Graphs: CascadeManager automatically triggers downstream policy updates, while Coefficient of Variation (CV) reflections auto-generate constraint atoms from observed historical data trends.
• Analytical Cold Tier: Leveraging pyarrow.dataset for high-performance cross-epoch scanning and numeric aggregation directly over compressed Parquet archives.
• ACID Crash Recovery: Zero data loss for in-flight memories via the synchronous Write-Ahead Log.

---

#License

MIT — see LICENSE.
